can be recorded, saved and analyzed as measured values. For this, it is first automatically checked whether the page contains errors.īy setting signals, positions, switching states, pressures etc. Simulate the created pneumatic circuits and display their behavior. Their signals are directly linked to the pneumatic components. Various settings can be made for the individual components.įor electro-pneumatics, electrical circuits can be created with the editor. The editor contains an extensive library of pneumatic elements.
Use the pneumatic-lab for training or for the design and / or simulation of industrial pneumatic systems. Arbitraty pneumatic circuits and electro-pneumatic controls can be created using the intuitive editor.Ĭreate GRAFCET plans and use them to describe the workflow of the pneumatic circuits or execute them as controls on your systems.
FlowLab is a comprehensive software for creation, simulation and control of pneumatic and electro-pneumatic circuits.
